| Item | Value |
| Active Rage | ≥92dB |
| S/N Ratio | ≥98dB |
| T.H.D | THD<0.5% |
| Freq. Response | 20Hz ~ 20KHz |
| Input Impedance | Low level input:15KΩ; High level input:10Ω |
| Low level output impedance | 560Ω |
| Output Power (max) | Power amplifier: 4x50W@4Ω (Class AB) |
| Signal input range(max) | RCA:3Vpp; High level:18.3Vpp |
| Signal output range(max) | RCA:3Vpp; Amplifier output:24Vpp |
| Ambient temperature | -30 ~ 70℃ |
| Supply Voltage | DC 10V ~ 17V |
| REM input | High level start (FR+/FR-), ACC star optional |
| REM output | +12V starting voltage output ( 0.06A ) |
| Power consumption | ≤0.1W |
| Net Weight | About 0.84kg |
| Dimension | 17012044mm |
